HybriDo Series Combined laser and mechanical machining
The HybriDo is equipped with high performance German spindle. All axis servo motor and full automatic 12 tool changer guaranteed very fast drilling and routing speed. System build-in vision system can share the very exact position for laser system. Because the drilling and structuring process are shared with the same vision and positioning system, the best accuracy can be guaranteed.
Thanks to DCT′s patented chemical-free S&S process, PCB can be produced in just a few minutes without burning the substrate material. Especially RF and microwave circuits benefit from exact feature dimensions and straight edges, providing a perfect fit of the circuit to the simulation results. With help of vacuum table, the flexible materials can be freely positioned and held. The HybriDo is also suitable for FPC or multilayer PCBs.
Product parameters
Technical data | HybriDo R1 |
Min. line width | 0.1mm (depend on material) |
Min. space | 0.05mm (depend on material) |
Structuring speed | 12cm2/min (depend on material) |
Min. hole diameter | 0,2mm |
System repeatability | ≤± 2μm |
Repeat postioning accuacy | ±2μm |
Resolution Scan field | ≤1μm |
X/Y step Resolution | 0.5μm |
Drilling speed | 120 /s |
Routing speed | 5mm/s (depend on material and thickness) |
Spindle speed | 80,000 rpm |
Laser wavelength | 1064nm Fiber laser |
Laser power | 30W |
Axis drive | X,Y,Z axis with servo motor |
Power supply | 220VAC 50Hz, 1600w |
Compressed air supply | Min. 6 bar; 80 L/min @ 6 bar |
Dimension (W x H x D) | 880mm x 800 mm x 961 mm (without signal light) |
Weight | 120 kg |
Configuration & Option | HybriDo R1 |
Vision and automatic positioning system | Standard |
Vacuum table | Standard |
Metal hausing | Standard |
Quadratic elementmeasure (basic function) | Standard |
Data processing software CircuitCAM | Standard |
Machine operation software DreamCreaTor | Standard |
PCB design software Edwin | Standard |
External quiet vacuum cleaner | Option |
Air compressor | Option |
Laser Goggles | Option |
PC | Standard |
